TECHNICAL PARAMETERS
|
Printhead
|
Epson DX5 micro piezo and stainless steel cartridge
|
|
Number of printhead
|
1
|
|
Number of nozzles
|
1440（180*8）
|
|
Resolution
|
1440dpi
|
|
Colors
|
C M Y K
|
|
Color gamut
|
16.7million
|
|
Width of worktable
|
1600MM(W)/1600MM(S)
|
|
Printing width
|
1600MM(W)/1600MM(S)
|
|
Speed
|
4pass
|
15㎡/h
|
|
6pass
|
10.5㎡/h
|
|
8pass
|
7.5㎡/h
|
|
Ink types
|
water-based;solvent-based;thermal transfer
|
|
Color management
|
ICC based; density& curves adjustment
|
|
RIP
|
Maintop5.3
|
|
Operation system
|
Windows XP
|
|
Interface
|
USB2.0
|
|
Power supply
|
50Hz/60Hz,220V 10A
|
|
Heating system
|
Three section heating:Pre-heater,bed-heater and rear-heater.
|
|
File forms
|
Bmp,TIF,Jpg,Pdf
|
|
Feeding method
|
roll to roll; leaf
|
|
Humidity
|
40%——70%
|
|
Dimension
|
2.6M*0.6M*1.1M
|
|
Weight
|
150Kg
|
|
